Example: OVP alarm
Before setting the protection settings:
Ensure the load is not connected.
Ensure the output is turned off.
You can use the Function settings (F-13 and F-14) to
apply limits to the voltage and current settings,
respectively. You can set limitations so that the values
do not exceed the set OVP and the set OCP level, and
so that the values are not lower than the set UVL trip
point.
By using this feature, you can avoid turning the output
off by mistakenly setting the voltage or current to a
value that exceeds the set OVP or OCP level or to a
value that is lower than the set UVL trip point.
If you have selected to limit the voltage setting (F-14),
you will no longer be able to set the output voltage to
a value that is above about 95% of the OVP trip point
or to a value that is lower than the UVL trip point.
If you have selected to limit the current setting (F-13),
you will no longer be able to set the output current to
a value that is above about 95% of the OCP trip point.
