GW Instek PSU Series User Manual

PSU Series User Manual
94
Configuration Overview
Configuration of the PSU power supplies is divided into five
different configuration settings: Normal Function, USB/GPIB, LAN,
UART, System Configuration Settings, Power ON Configuration,
Trigger Input/Output Configuration Settings and Special Function
Settings. Power ON Configuration differs from the other settings in
that the settings used with Power ON Configuration settings can
only be set during power up. The other configuration settings can
be changed when the unit is already on. This prevents some
important configuration parameters from being changed
inadvertently. Power On Configuration settings are numbered F-90
to F-98 and the other configuration settings are numbered F-00 to F-
61, F-70 to F-78, F-88 to F-89 and F100 to F122. The Special Function
Settings are used for calibration, firmware updated and other
special functions; these functions are not supported for end-user
use.
Configuration Table
Please use the configuration settings listed below when applying
the configuration settings.
Normal Function
Settings
Setting
Setting Range
Output ON delay time
F-01
0.00s~99.99s
Output OFF delay time
F-02
0.00s~99.99s
V-I mode slew rate select
F-03
0 = CV high speed priority (CVHS)
1 = CC high speed priority (CCHS)
2 = CV slew rate priority (CVLS)
3 = CC slew rate priority (CVLS)
Rising voltage slew rate
F-04
0.001~0.060V/msec (PSU 6-200)
0.001~0.080V/msec (PSU 8-180)
0.001~0.125V/msec (PSU 12.5-120)
0.001~0.150V/msec (PSU 15-100)
0.001~0.200V/msec (PSU 20-76)
0.001~0.300V/msec (PSU 30-50)
0.001~0.400V/msec (PSU 40-38)
0.001~0.500V/msec (PSU 50-30)
