CONFIGURATION
109
E-XX = Kernel build month
F-XX = Kernel build day
G-XX = Test command version (1/2)
H-XX = Test command version (2/2)
I-XX = Test command build year (1/2)
J-XX = Test command build year (2/2)
K-XX = Test command build month
L-XX = Test command build day
M-XX = Reserved (1/2)
N-XX = Reserved (2/2)
O-XX = Option module (1/2)
P-XX = Option module (2/2)
Power On Configuration Settings
CV Control
Sets the constant voltage (CV) control mode
between local and external voltage/resistance
control. For external voltage control, see page 121
(External Voltage Control of Voltage Output) and
page 125 (External Resistance Control of Voltage
Output). For Isolated control, see page 142 for
details.
F-90
0= Control by local
1 = Control by external voltage
2 = Control by external resistor -
rising
3 = Control by external resistor-
falling
4 = Control by isolated board
CC Control
Sets the constant current (CC) control mode
between local and external voltage/resistance
control. For details on external voltage control, see
page 123 (External Voltage Control of Current
Output) and 128 (External Resistance Control of
Current Output). For Isolated control, see page 142
for details.
F-91
0 = Control by local
1 = Control by external voltage
