PSU Series User Manual

112

Trigger Output

Pulse Width

Trigger output pulse width. A setting of 0 will

output the active level.

F120

0 ~ 60ms. 0 = output active level

Trigger Output

Level

Sets the active level of the output trigger if the

trigger output pulse width (F120) = 0.

F121

0 = LOW

1 = HIGH

Trigger Source

Sets the trigger source.

F122

0 = None

1 = Switching the output on/ off

2 = Changing a setting

3 = Recalling a memory

Special Function

The special function setting is used to access

calibration, firmware updates and other special

functions. The special function setting has a

password that is used to access the special function

menu. The password used determines which

function is accessed. Please see your distributor for

details.

F-00

0000 ~ 9999

Setting Normal Function Settings

The Normal Function settings, F-01~F-61, F-70~F-

78, F-88~F-89 and F100~F122 can be easily

configured with the Function key.

 Ensure the load is not connected.

 Ensure the output is off.

 Function settings F-90~98 can only be viewed.
