GW Instek PSU Series - UART Communication Settings Configuration

CONFIGURATION
107
UART Settings
UART Mode
Sets the UART mode or disables UART.
F-70
0 = Disable UART, 1 = RS232,
2= RS485 4W, 3 = RS485 2W
UART Baud Rate
Sets the UART baud rate.
F-71
0 = 1200, 1 = 2400, 2 = 4800,
3 = 9600, 4 = 19200, 5 = 38400,
6 = 57600, 7 = 115200
UART Data Bits
Sets the number of data bits.
F-72
0 = 7 bits, 1 = 8 bits
UART Parity
Sets the parity.
F-73
0 = None, 1 = Odd, 2 = Even
UART Stop Bit
Sets the number of stop bits.
F-74
0 = 1 bit, 1 = 2 bits
UART TCP
UART transmission control protocol TCP settings.
This is used primarily for multi-unit remote
control, see page 170.
F-75
0 = SCPI, 1 = TDK (emulation mode)
Note
Please refer to the TDK Genesys Series user manual
for the TDK control commands.
UART Address
(For multi-unit
remote control)
UART Address: this is used to set the address of a
unit when using multi-unit remote control, see
page 170 for details.
F-76
0 ~ 30
