GW Instek PSU Series User Manual

APPENDIX
205
Model
PSU
100-15
150-10
300-5
400-3.8
600-2.6
Efficiency
*13
100Vac
%
84
84
84
84
84
200Vac
%
87
87
87
87
87
Model
PSU All models
Hold-up time
20ms or greater
Interface Capabilities
Model
PSU All models
USB
TypeA: Host,
TypeB: Slave,
Speed: 1.1/2.0, USB
Class: CDC(Communications Device Class)
LAN
MAC Address, DNS IP Address, User Password, Gateway IP
Address, Instrument IP Address, Subnet Mask
RS-232/RS-485
Complies with EIA232D / EIA485 Specifications
GPIB (Factory Option)
SCPI - 1993, IEEE 488.2 compliant interface
Environment Conditions
Model
PSU All models
Operating temperature
0˚C to 50˚C
*14
Storage temperature
-25˚C to 70˚C
Operating humidity
20% to 85% RH; No condensation
Storage humidity
90% RH or less; No condensation
Altitude
Maximum 2000m
General Specifications
Model
PSU All models
Weight
main unit only
kg
Less than 8.7kg
Dimensions
(W×H×D)
mm
423 x 43.6 x 447.2
Cooling
Forced air cooling by internal fan.
EMC
Complies with the European EMC directive for Class
A test and measurement products.
Safety
Complies with the European Low Voltage Directive
and carries the CE-marking.
Withstand
voltage
AC to Chassis: 1500Vac/1min
AC to Output terminal: 3000Vac/1min
Output terminal to Chassis:
Vout ≤ 150V: 1000Vdc/1min
150V<Vout ≤600V: 1500Vdc/1min
Insulation
resistance
Chassis and output terminal; chassis and AC input;
AC input and output terminal: 100MΩ or more (DC
1000V)
