PSU Series User Manual
206
Notes:
*1
Minimum voltage is guaranteed to maximum 0.2% of the rated output voltage.
*2
Minimum current is guaranteed to maximum 0.4% of the rated output current.
*3
At 85 ~ 132Vac or 170 ~ 265Vac, constant load.
*4
From No-load to Full-load, constant input voltage. Measured at the sensing point in
Remote Sense.
*5
Measure with JEITA RC-9131B (1:1) probe
*6
Measurement frequency bandwidth is 10Hz to 20MHz.
*7
Measurement frequency bandwidth is 5Hz to 1MHz.
*8
From 10% to 90% of rated output voltage, with rated resistive load.
*9
From 90% to 10% of rated output voltage, with rated resistive load.
*10
Time for output voltage to recover within 0.5% of its rated output for a load change from
0 to 90% of its rated output current. Voltage set point from 10% to 100% of rated
output.
*11
For load voltage change, equal to the unit voltage rating, constant input voltage.
*12
For 6V~20V model the ripple is measured at 2V ~ rated output voltage and full output
current. For other models, the ripple is measured at 10 ~ 100% output voltage and full
output current.
*13
At rated output power.
*14
If install the front panel filter kit, the temperature is guaranteed to 40˚C.
