GW Instek PSU Series - Socket Server Function Check

PSU Series User Manual
186
1. Connect an Ethernet cable from the
network to the rear panel Ethernet
port.
LAN
2. Press the Function key to enter the
Normal configuration settings.
Function
Set the following LAN settings:
F-36 = 1
Enable LAN
F-37 = 0
Disable DHCP
F-39 = 172
IP Address part 1 of 4
F-40 = 16
IP Address part 2 of 4
F-41 = 5
IP Address part 3 of 4
F-42 = 133
IP Address part 4 of 4
F-43 = 255
Subnet Mask part 1 of 4
F-44 = 255
Subnet Mask part 2 of 4
F-45 = 128
Subnet Mask part 3 of 4
F-46 = 0
Subnet Mask part 4 of 4
F-47 = 172
Gateway part 1 of 4
F-48 = 16
Gateway part 2 of 4
F-49 = 21
Gateway part 3 of 4
F-50 = 101
Gateway part 4 of 4
F-57 = 1
Enable Sockets
Socket Server Function Check
Background
To test the socket server functionality, National
Instruments Measurement and Automation
Explorer can be used. This program is available on
the NI website, www.ni.com., via a search for the
VISA Run-time Engine page, or “downloads” at
the following URL, http://www.ni.com/visa/
Requirements
Operating System: Windows XP, 7, 8
Functionality
check
1. Start the NI Measurement and Automation
Explorer (MAX) program. Using Windows,
