We reserve the right to make changes of a technical nature 23
Information about the FWB, FWQ distribution board range
4.2.2 Coding
The order number coding for FWB distribution boards consists of three components:
- Cabinet type: FWB… (Basic fixation)
- Cabinet dimensions (height and width): FWB32…
Cabinet width
Cabinet height 300 mm 550 mm 750 mm 1050 mm
500 mm 31 32 33 34
650 mm 41 42 43 44
800 mm 51 52 53 54
950 mm 61 62 63 64
1100 mm 71 72 73 74
1250 mm 81 - - -
-
Cabinet configuration: FWB32GS
The various cabinet configurations are summarised in the following table:
Reference
ending
With internal
system
Internal
system
With
terminals
Terminal
type
With
door
Door
type
Door
plate
Without Yes Distribution panel Yes
Brass
terminals
Yes Plain FZ598N
A Yes Distribution panel No (Empty) Ye s Plain FZ598N
CSDB Yes
Distribution panel +
main switch
Yes
PE
QuickConnect
Yes Plain FZ598N
D No (Empty) No (Empty) Ye s Plain FZ598N
D1 No (Empty) No (Empty) (Empty) (Empty)
GS Yes Distribution panel Yes
N + PE
QuickConnect
Yes Transparent FZ598N
K1 Yes
Distribution panel -
multimedia panel
Yes
N + PE
QuickConnect
Yes Slotted FZ598N
K5 Yes
Distribution panel -
multimedia panel
Yes
PE
QuickConnect
Yes Plain FZ598N
M2 Yes Distribution panel Ye s
PE
QuickConnect
Yes Plain FZ598N
N Yes Distribution panel No
(Prepared
for DIN rail
terminals)
Yes Plain FZ598N
N3 Yes Distribution panel No
(Prepared
for DIN rail
terminals)
Yes Plain FZ598N
P Yes Distribution panel Yes
PE
QuickConnect
Yes Plain FZ598N
P2 Yes
Distribution panel +
empty panel
Yes
PE
QuickConnect
Yes Plain FZ598N
S Yes Distribution panel Yes
N + PE
QuickConnect
Yes Plain FZ598N
T1S Yes Distribution panel Yes
PE
QuickConnect
No (Empty) (Empty)
