hager FWB Series User Manual

We reserve the right to make changes of a technical nature 37
Information about the FWB, FWQ distribution board range
4.2.4.10 FWBxxN
Reference
FWB52N
FWB53N
FWB62N
FWB63N
FWB64N
FWB72N
FWB73N
FWB74N
Example: FWB62N
Protection class IP44, impact protection IK09
Internal system:
2 top rows:
- For DIN rail terminals
- Plain covers, 15 mm depth
- Insulated DIN rails, 15 mm depth
- Distance between the DIN rails: 150 mm
Distribution panel(s):
- Covers with 12 module slot width. Cover configuration, see page 39
- Distance between the DIN rails: 150mm
Without QuickConnect terminals and without QuickConnect carrier
Door:
- Plain
- Steel
- univers door closing
- Right door with reinforcement bar for size 5 and higher
Included in scope of delivery:
- DINA4 – labelling strip with type label
- DINA4 – circuit table
- FWB – installation instructions
