hager FWB Series User Manual

We reserve the right to make changes of a technical nature 87
univers Z internal system
7.4.2 Berker Integro Design Flow patch panel with socket insertion
UM00K3
A special patch panel and socket combination has been developed for the German market.
The UM00K3 mount has 1 opening each on the left and right side for Berker Integro Design Flow sockets
and 10 patch openings in the centre.
UM00K3
E-DAT inserts such as: VZ31xxx can be installed in the centre area of the patch panel.
VZ314RJ VZ318LC
Berker Integro Design Flow inserts can be screwed in on the left and right. 8 screws are supplied with the
UM00K3 patch panel for this purpose. Inserts are available through the Berker references 9... or as accessories
for Volta Hybrid range VZ00HB and VZ00HD.
VZ00HB VZ00HD 945602502
