Enclosure installation
6.2 Cabinet feet
FWB and FWQ cabinets are supplied with two long plastic parts that are inserted beneath the cabinet,
the so-called “cabinet feet” as standard. These parts ensure that the cabinet stands securely in a vertical
position at the construction site prior to installing them on the wall and protect the bottom cable entry flanges
and bottom against scratches and deformation.
Figure: Cabinet feet left / right
Although the standards do not specify it as compulsory, these plastic parts can be removed and disposed
of once the cabinet has been installed on the wall for aesthetic reasons, either manually or with a flathead
screw driver. Two sealing parts are supplied with all cabinets for sealing the resulting holes.
