We reserve the right to make changes of a technical nature 49
Doors
5 Doors
5.1 Properties
- Front-flush, can be hinged on the right or left
- Removable without tools, door stop removable without tools
- Interior, adjustable hinges
- Can be supplied with metal doors (plain door), see-through doors (transparent door) or multimedia plastic
doors (multimedia door)
- Two doors at a cabinet width of 800 and 1050 mm. Right doors (with lock and poles) maximum 2-panel
in width. Left doors (without lock and poles) maximum 2-panel in width.
- Door opening angle: 110°
- Protection class and impact protection: see chapter 3, Technical data
- Standard colour: RAL 9010
- Door closing latch can be sealed as standard and retrofitted with a key or special lock
- FWB-, FWQ doors are supplied with FZ598N door plate as standard (univers door closing)
- 3-point bar locking with locking lever with centre T-handle and push rods at the top / bottom
- 2-panel right and left doors have a reinforcement bar in the centre of the rear by size 5 (750 mm) and
higher
FWB and FWQ cabinets with doors (left / right) are equipped according to the following door combinations:
Width: 1
module
1-panel
Width: 2
modules
2-panel
Width: 3
modules
3-panel
Width: 4
modules
4-panel
-
Door distance to internal elements: see image next page
