50 We reserve the right to make changes of a technical nature
Doors
2:1
A-A
161
26.2
26
4.9
57.5
7.5
47.5
105.8
52
059
156.4
100.5
108
48.4
50.5
52
009
22.2
7
6
5
4
3
1
2
Note for door mounting: distances from door to internal system components
1 Distance Vertical mounting rail – Cover exterior wall
2 Distance Vertical mounting rail – Door exterior wall
3 Distance DIN rail – Cover interior wall
4 Distance DIN rail – Door exterior wall
5 Distance Cover exterior wall – Door exterior wall
6 Distance Plastic board back panel – Door exterior wall
7 Distance Mounting plate – Door exterior wall
