We reserve the right to make changes of a technical nature 73
univers Z internal system
7.3.3 DIN rails U…
The following univers Z DIN rails can be ordered separately. The rail profile is 35 x 7,5 x 1 mm.
U842B: 7,5mm DIN rail standard (12 modules width) U842C: Din rail 26 modules
U82A: 7,5mm DIN rail, insertable (200 mm length)
1-panel, adjustable depth up to 32.5 mm
- 5 mm
- 12 mm
- 25 mm
- 32.5 mm
(without part A)
A
UT22B: 7,5mm DIN rail, insulated, insertable (200 mm
length) 1-panel, recessed depth 31 mm (non adjustable)
