Information about the FWB, FWQ distribution board range
The order number coding for FWQ distribution boards consists of three components:
- Cabinet type: FWQ… (Quickset fixation)
- Cabinet dimensions (height and width): FWQ32…
- Cabinet configuration: FWQ32P
The various cabinet configurations are summarised in the following table:
Reference
ending
With internal
system
Internal
system
With
terminals
Terminal
type
With
door
Door
type
Door
plate
D1 No (Empty) No (Empty) No (Empty) (Empty)
N Yes Distribution panel No
(Prepared
for DIN rail
terminals)
Yes Plain FZ598N
N1 Yes Distribution panel No
(Prepared
for DIN rail
terminals)
No (Empty) (Empty)
P Yes Distribution panel Ye s
PE
QuickConnect
Yes Plain FZ598N
P1 Yes Distribution panel Yes
PE
QuickConnect
No (Empty) (Empty)
The various cabinet dimensions are listed in the following chapter “Cabinet references overview”.
4.2.3 Cabinet references overview
4.2.3.1 FWB references
Size 3 Cabinet width
300 mm 550 mm 750 mm 1050 mm
Cabinet height
500mm
FWB31 FWB32 FWB33A FWB34A
FWB31A FWB32A FWB33D FWB34D
FWB31D FWB32D FWB33D FWB34D
FWB31D1 FWB32D1 FWB33D1 FWB34D1
FWB31GS FWB32GS FWB33GS FWB34GS
FWB31P FWB32K1 FWB33P FWB34P
FWB31S FWB32M2 FWB33S FWB34S
FWB31T1S FWB32P FWB33T1S FWB34T1S
- FWB32S - -
- FWB32T1S - -
