72 We reserve the right to make changes of a technical nature
univers Z internal system
7.3 Supply of individual panel versions
Panels can be assembled from individual parts. The accessories required for this purpose are listed in the
following chapters.
7.3.1 univers Z UN0xA mounting rails
Contents
Height
Width 1
(250 mm)
2 mounting rails with 4
fixing screws, 34.5 mm
length
3 (450 mm) UN03A
4 (600 mm) UN04A
5 (750 mm) UN05A
6 (900 mm) UN06A
7 (1050 mm) UN07A
8 (1200 mm) UN08A
UN03A
7.3.2 UZ0xAx fixation towers
UZ03A1: fixation tower bottom parts left + right UZ04A1: Twin tower / twin fixation tower
UZ01A2 (1x) UZ01A4 (4x) UZ01A1 (100x)
fixation tower top part
