univers Z internal system
Example: UN51B2
Panels Height Width 1 (250mm) PEN holder QC clamp
Mounting plate
UM00M0
2 x DIN rail at the top,
Multimedia field with
plastic mounting plates at
the bottom
5 (750 mm) UN51B2 KN00A KN18E 2 x
6 (900 mm) UN61B2 KN00A KN18E 2 x
Example: UN71B3
Panels Height Width 1 (250mm) PEN holder QC clamp
Mounting plate
UM00M0
3 x DIN rail at the top,
Multimedia field with
plastic mounting plates at
the bottom
6 (900 mm) UN61B3 UZ00K1 KN18E 2 x
7 (1050 mm) UM71M3 UZ00K1 2xKN10N + KN18E 2 x
UN71B3 UZ00K1 KN18E 2 x
8 (1200 mm) UM81M3 UZ00K1 2xKN10N + KN18E 3 x
UN81B3 UZ00K1 KN18E 3 x
