Hammer K2 M - Page 16

16
Adjustments and tool changes
NOTICE
Incorrectly adjusted distance between the saw blade and riving
k
nife
Material damage and possible malfunction with covered cuts.
− The gap between the riving knife and saw blade must be
be
tween 3 and 8 mm.
− When carrying out covered cuts, the highest point of the riving
k
nife must be 0-2 mm below the highest point of the saw
blade.
Tool:
● Spanner 17 mm
1.
Preparing the machine for a tool change. ⮫
Chapter 1.3.2 ‘Prepare to
change tooling’ on page 11
2.
Loosen the clamping screw.
3.
Move the riving knife so that there is, at any given point, a distance of 3 to
8 mm be
tween the saw blade and the riving knife.
4.
The marking on the riving knife must match the top edge of the machine
t
able at the max. cutting height (independently of the saw blade used).
5.
When carrying out covered cuts, the highest point of the riving knife must be
0-2 mm be
low the highest point of the saw blade.
6.
WARNING F
lying pieces
Severe injuries and damage to property.
● Minimum tightening torque of the clamping bolt: 25 Nm.
Tighten the clamping screw.
