Adjustments and tool changes
Correct selection of the riving knife
Fig. 13: Suitable riving knife for the saw blade
1 Riving knife thickness (d)
2 Saw tooth width (D)
3 Saw blade body (S)
The riving knife has to be adapted to the thickness of the saw blade. The thickness
of the r
iving knife must be between that of the saw blade body and the width of
the saw tooth.
The riving knife must be adapted to the saw blade diameter. Observe the mark-
ings on the riving knife.
Fig. 14: Riving knife markings
1 Saw blade diameter
2 Riving knife thickness
3 Saw blade diameter markings
