K2 M - Part 2/2
Troubleshooting
Check the setting by making a 2-sided sample cut
1
3
2
Fig. 41: Sample cut - Crosscut fence angle
1 First cut (reference cut)
2 Rotate the workpiece in a clockwise direction
3 Second cut (control cut)
Tool:
● Angle gauge
● Test workpiece (panel material)
1.
Set saw cutting angle and crosscut fence to 0°.
2.
Carry out sample cut (reference cut).
3.
Turn the test workpiece 90° in a clockwise direction.
🡆
Let the workpiece rest with the cut side against the stop.
4.
Carry out a sample cut again (control cut).
5.
Check the result with an angle gauge.
🡆
Place the angle gauge on both of the cut surfaces.
