1.5 - SYMBOLS LEGEND AND DEFINITIONS
Symbols are used throughout this manual to depict hazards, avoidance measures and indicate
when information is required.
Refer to the following table to familiarize yourself with these symbols.
Symbol Description Symbol Description Symbol Description
Body crushing hazard
Foot crushing hazard
High pressure fluid ejection
hazard
Hand crushing hazard Entanglement hazard
Health/safety hazards
related to chemicals
Health-damaging effects from
hot work environment
Electrical contact or
lightning strike
Burns and scalds from
contact with flames,
explosion or radiation from
heat sources
Injury from Electric arcs -
Energy supply disconnecting
devices - Batteries fire,
emissions, etc
Risk of operator(s) falling
Tip over due to excessive
loading / wind load and
excessive ground slope
Relate and coordinate
directional arrows on the
chassis with those on the
control box
Do not put foot in this area
Do not put your hand in this
area
Keep away from product
working area
Never expose batteries
and electrical component
to high pressure washer
Ensure entry drop rail is
down
Flames prohibited
Maintain safe clearance
from high voltage
electrically charged
conductors as described in
manual - Do not use in
thunderstorms
Overload
Refer to operator manual Safety belt
Use appropriate lanyard
attached to dedicated anchor
point.
Wheel pressure Enable switch
Use safety prop before
attempting any maintenance
work
Tow point Tie down point Lift point
Keep away from hot
surfaces
Wear protective equipment
x 1
