76 4000670450 E 04.19 USA / GB
D
- Operation instructions
3632T - HTT13
6 - Transportation
6.1 - PUTTING IN TRANSPORT POSITION
• Completely retract and lower all booms into the stowed position.
• Secure both boom travel latches ( A ).
• Remove all loose materials from machine.
• All on-board equipment is secured.
• Retract all outriggers cylinders to fully stowed (upright) position.
• The TONGUE JACK / DOLLY WHEEL and outriggers are in their travel positions. The
TONGUE JACK / DOLLY WHEEL is rotated up so that the TONGUE JACK / DOLLY WHEEL
assembly is parallel with the tongue tube; the outrigger cylinders are fully retracted.
• The key switch is in the OFF position. Remove the key.
• The trailer tires are adequately and evenly inflated. See the side wall of the tire for proper
inflation.
6.1.1 - Machine layout
Machine layout
