57 4000670450 E 04.19 USA / GB
C - Pre-operation inspection
3632T - HTT13
4 - Safety functional checks
To protect the user and the machine, safety systems prevent the movement of the machine beyond its
operating limits. These safety systems when activated immobilize the machine and prevent further
movement.
The operator must be familiar with this technology and understand that is not a malfunction but an
indication that the machine has reached an operation limit.
Aerial Work platforms are equipped with two control boxes which allow operators to safely use the
machine. An auxiliary device (T-handle) is available on the chassis to assist with the emergency
lowering of the machine. Each control box is equipped with an E-Stop button, which cuts all movements
when pushed in.
The following checks describe the operation of the machine and the specific controls required.
The speed selector buttons at the ground control box and the platform control box act as the enable
switch.
For the location and description of these controls : refer to section B 3.3 and D 2 Ground control
box and B 3.4 and D 3 Platform control box.
4.1 - E-STOP BUTTON CHECK
Ground control box E-stop button
Platform control box E-stop button
Step Action
1 Pull both E-Stop buttons ( 6 ) at ground box and ( 5 ) at platform box.
2
Turning the KEY SWITCH ( 1 ) counter clockwise to the GROUND ( 1b ) icon selects operation from the
ground (lower) control box.
3
Start a cold engine by pressing (pushing) in and holding the CHOKE ( 4 ) button then press (push) the
ENGINE START ( 3 ) button.
To start / restart a warm engine, press (push) the ENGINE START ( 3 ) button only.
4 Push the E-stop button ( 6 ).
5 Check that the engine stops running.
6 No movements are functional.
Step Action
1 Pull out the E-Stop button ( 6 ) at ground box.
2
Turning the KEY SWITCH ( 1 ), clockwise to the PLATFORM ( 1a ) icon selects operation from the platform
(upper) control box.
3 Pull out the E-Stop button ( 5 ) at platform box.
4
Start a cold engine by pressing (pushing) in and holding the CHOKE ( 2 ) button then press (push) the
ENGINE START ( 1 ) button.
To start / restart a warm engine, press (push) the ENGINE START ( 1 ) button only.
5 Push in E-Stop button ( 5 ) at platform.
6 Check that the engine stops running.
7 No movements are functional.
