Haulotte HTT13 - Operation from the Ground Control Box

64 4000670450 E 04.19 USA / GB
D - Operation instructions
3632T - HTT13
1.2 - OPERATION FROM THE GROUND CONTROL BOX
Refer to Section B 3.2 - Ground control box.
• Turning "ON" and "OFF" of the machine is performed with the Control box activation key
switch ( 1 ).
• Activation of a desired control box is achieved by turning the Control box activation key
switch ( 1 ) to the desired position ( 1a ) ( 1b ).
• The ground control box is energized and is active ONLY when :
• The E-stop buttons on both ground and platform control boxes are not pressed in (Deactivated).
• To switch ON the machine, turn the Control box activation key switch ( 1 ) at the ground control box on ground
control box position ( 1b ).
• An E-Stop button at each control box stops all movements when pressed in; including
shutting off an engine (if equipped).
N.B.-:-DO NOT
TURN OFF THE POWER SUPPLY OF THE MACHINE USING THE E-STOP BUTTON(USE
ONLY IN CASE OF EMERGENCY). TURN OFF THE POWER SUPPLY OF THE MACHINE USING THE
CONTROL BOX ACTIVATION KEY SWITCH (1) TO POSITION.
• All switches operating a movement, return automatically to neutral when released.
• At power up, all switches must be in their neutral position.
• The status of the controls is tested automatically when the machine is switched on. A control
will be active only after it has been detected to be in neutral position.
• A control ( 3 ) provides the start and stop of the engine.
• A buzzer beeps in the following conditions :
• When power is switched on.
• Overload (if fitted).
• Indicators : Indicators ( 2 ), ( 20 ), and ( 21 ) are checked when the machine is powered on.
• Display panel : All indicators ( 5 ) are checked when the machine is powered on.
