58 4000670450 E 04.19 USA / GB
3632T - HTT13
C
- Pre-operation inspection
4.2 - ACTIVATION OF CONTROLS
The speed/enable button at ground control box ( 15 ) and platform control box ( 6 ) must be
actived to allow any movement.
4.3 - FAULT DETECTOR
The machine is equipped with an on-board fault detection system, which indicates the type of
fault to the operator.
The fault is identified by a default code.
The default code is displayed at the ground control box.
According to the type of fault, the machine MAY switch into DOWNONLY mode and certain
movements are prevented to maintain Operator's safety.
Do not use the machine until the fault has been corrected.
4.3.1 - Indicators/LED's test
From the ground control box
From the platform control box
Step Action
1 Pull both the E-Stop buttons ( 5 ) at platform box and ( 6 ) at ground box.
2 Set the key switch ( 1 ) at ground box to the ( 1b ) position.
3 Check that the indicators (2), (20) and the display ( 5 ) are lit.
4 Check that the indicators turn off in few seconds.
Step Action
1 Pull both the E-Stop buttons ( 5 ) at platform box and ( 6 ) at ground box.
2 Set the key switch ( 1 ) at ground box to the ( 1a ) position.
3 Check that the battery indicators light up and flash.
4 Check that the indicators turn off in few seconds.
