D - Operation instructions
3632T - HTT13
1.3 - OPERATION FROM THE PLATFORM CONTROL BOX
Refer to Section B 3.3 - Platform control box.
• The platform control box is energized only when :
• The E-stop buttons on both ground and platform control boxes are not pressed in.
• To switch ON the machine, turn the Control box activation key selector ( 1 ) at the ground control box on ground
control box position ( 1a ).
• An E-Stop button at each control box stops all movements when pressed in; including
shutting off an engine (if equipped).
N.B.-:-DO NOT
TURN OFF THE POWER SUPPLY OF THE MACHINE USING THE E-STOP BUTTON(USE
ONLY IN CASE OF EMERGENCY). TURN OFF THE POWER SUPPLY OF THE MACHINE USING THE
CONTROL BOX ACTIVATION KEY SWITCH (1) TO POSITION.
• All switches operating a movement, return automatically to neutral when released.
• At power up, all switches must be in their neutral position.
• The status of the switches is tested automatically when the machine is switched on and
checked at every starting. A switch will be activated only after it has been detected in neutral
position.
• A buzzer beeps in the following conditions :
• When power is switched on.
• When platform is overloaded (if fitted).
• When machine is on a slope greater than the rated slope.
• Emergency pump. ( Section D 4.1 In case of engine power failure)
• Indicators - All indicators are checked after powering on the machine.
