Haulotte HTT13 - Major Component Masses; Acoustics and Vibrations

86 4000670450 E 04.19 USA / GB
E - General Specifications
3632T - HTT13
2 - Major component masses
N.B.-:-MASSES MEASURED WITH EMPTY TANKS (STANDARD MACHINE-NO OPTIONS).
Note :
• Drive and set option adds 113 kg (250 lbs).
• Machine generator option adds 86 kg (190 lbs).
• Basket Rotate and spare tire options add 68 kg (150 lbs) to weight.
3 - Acoustics and vibrations
The acoustics and vibrations specifications are based upon the following conditions :
Component 3632T - HTT13P
Characteristics-Dimensions SI Imp.
Boom assembly 438 kg 964 lbs
Turntable assembly 815 kg 1796 lbs
Trailer assembly 756 kg 1667 lbs
Total weight 2008 kg 4427 lbs
Specifications
DC mode - Ground (Lower) 60 dBA
DC mode - Platform (Upper) 55 dBA
Engine mode - Ground (Ground) 70 dBA
Engine mode - Platform (Upper) 65 dBA
