Haulotte HTT13 - Performance Specifications; Technical Characteristics

34 4000670450 E 04.19 USA / GB
3632T - HTT13
B - Familiarization
4 - Performance Specifications
4.1 - TECHNICAL CHARACTERISTICS
Use the table to select the right Haulotte machine for the job.
ANSI, CSA and AS standards
Machine HTT13 - 3632T
Characteristics - Dimensions SI Imp.
Maximum working height 13,4 m 43 ft 6 in
Maximum platform height 11,4 m 37 ft 6 in
Maximum horizontal outreach :
• From centerline of rotation
• From outrigger footpad edge
9,8 m
8,2 m
32 ft 0 in
27 ft 0 in
Rated platform capacity :
• Without platform rotator option
• With platform rotator option
227 kg
200 kg
500 lb
440 lb
Maximum number of occupants 2
Maximum wind speed allowed 45 km/h - 12.5 m/s - 28 mph
Total weight :
• Without option
• Drive and set option adds 113 kg (250 lb), Engine option adds 86 kg (190
lb), all other options add 68 kg (150 lb) to weight
3492 kg 7700 lb
Turntable rotation 700° non continuous
Leveling capability 12.5°
Manual force 400 N - 90 lbf
Platform rotation (Optional) 120° / Manual
Machines stowed dimensions :
• Height
• Length
• Width
2 m
6,7 m
1,7 m
6 ft 5 in
21 ft 11 in
5 ft 5 in
Outrigger footprint (Widest Point) :
• Length
• Width
4,19 m
4,11 m
13 ft 9 in
13 ft 6 in
Outrigger footprint (To center of pad ; Narrowest Point) :
• Length
• Width
• Footpad diameter
3,8 m
3,5 m
0,3 m
12 ft 4 in
11 ft 4 in
12 ft 5 in
Parking brake Mechanical
Towing brake
Hydraulic Surge
Mechanical
Electrical
Rated towing speed 105 km/h 65 mph
Tire size ST 225/75 R15D
Control system 24V DC
Battery 4 x 6V 245 amp-hr
Charger
110 Volt 60 Hz
220 Volt 50 Hz
Hydraulic pressure 207 bar 3000 psi
Reservoir capacity 18,2 l 4.8 Gallons
Hydraulic system capacity 26,5 l 7 Gallons
Hydraulic oil (Standard) HVI AW32
Localized Pressure per Outrigger 1,8 kg/cm2 (176,5 kPa) 25 psi
Operating Temperature Range From -20 °C(-4 °F) to 50 °C(122 °F)
