D - Operation instructions
3632T - HTT13
3.3 - ADDITIONAL CONTROLS
• Horn : Pressing (pushing) the HORN button ( 3 ) will sound the HORN.
• Use the horn button to warn personnel in the area of a falling object hazard, impending boom
motions or the need for assistance.
Boom telescoping extend
/ retract
Press the boom telescoping control ( 11 ) to extend the
boom.
Press the boom retracting control ( 12 ) to retract the
boom.
Turntable rotation
Press the turntable rotation control ( 7 ) for a clockwise
rotation .
Press the turntable rotation control ( 8 ) for an counterclockwise
rotation .
Platform leveling
Press the platform leveling control ( 13 ) to raise the
platform .
Press the platform leveling control ( 14 ) to lower the
platform .
Command Action
