- Familiarization
Marking Description Marking Description
C1 Slave cylinder C11 Coupler
C2 Extension boom C12 Outrigger pad
C3 Telescoping boom C13 Outrigger foot
C4 Master cylinder C14 Outrigger leg
C5 Axle C15 Outrigger cylinder
C6 Boom rest C16 Generator interface plate
C7 Latch release C17 Turntable
C8 Jack handle C18 Lift cylinder
C9 Dolly wheel C19 Platform
C10 Trailer hitch
