Mobile Video Recorder User Manual
13
Configure Local Network
Select LAN Choice.
Debug Interface: Used to debug the recorder.
Front Interface: Used to connect network cameras.
Do not set the debug and rear net to the same network segment. Otherwise, it will lead to conflict.
Enter network parameters: IPv4 Address, IPv4 Subnet Mask, and IPv4 Default Gateway.
Optional: To access the recorder via internet, configure DNS server.
Click Save.
