Mobile Video Recorder User Manual
26
Configure Sensor-in
Sensor-in detects and records the vehicle's driving information, including pedal braking, turning
left/right, reversing, etc.
Before You Start
Connect the recorder sensor-in interface and vehicle corresponding interface. For details, refer to
quick user guide.
If sensor-in is disabled, you can configure it via alarm input. For example, for the recorder with 4-ch
alarm inputs, according to the sequence of the parameters on the interface, braking corresponds
to No. 5 alarm input (A<-5), turning left corresponds to No. 6 alarm input (A<-6), and so on. Refer
to "Configure Alarm Input" for details.
Go to Configuration > Vehicle > Sensor-In.ć
Check Enable.
Select Trigger Level and Pop Channel according to actual situation.
The image of selected channel will be displayed in full screen when sensor-in is triggered.
Click Save.
