Digital Video Recorder User Manual
120
After you have configured the HDD groups, you can configure the recording settings following the
procedure provided in Chapter 5.2-5.7.
5.10 Files Protection
Purpose
You can lock the recorded files or set the HDD property to Read-only to protect the record files
from being overwritten.
Protect file by locking the record files
Step 1 Enter Export Settings interface.
Menu> Export
Figure 5-31 Export
Step 2 Select the channels you want to investigate by checking the checkbox to .
Step 3 Configure the record mode, record type, file type, start time and end time.
Step 4 Click Search to show the results.

Table of Contents

Other manuals for HIKVISION DS-7104HGHI-F1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7104HGHI-F1 and is the answer not in the manual?

HIKVISION DS-7104HGHI-F1 Specifications

General IconGeneral
Video CompressionH.264
Video Input4 channels
Audio Input1 channel
Audio Output1 channel
HDD Interface1 SATA interface
HDD CapacityUp to 6TB
USB Interface2 × USB 2.0
Power Supply12 VDC
Operating Temperature-10 °C to +55 °C
Operating Humidity10% to 90%
Video Output1 VGA, 1 HDMI
Network Interface1 RJ45 10M/100M Ethernet interface
