Each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and CH04...; and
each two channels in the same group must be connected with the same type of video source
(HDTVI or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
18.1.2 DS-7200HGHI-E1
Model
DS-7204HGHI-E1
DS-7208HGHI-E1
DS-7216HGHI-E1
Video/
Audio input
Video
compression
H.264+/H.264
Analog and
HDTVI video
input
4-ch
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Supported
camera types
720p25, 720p30, CVBS
IP video input
1-ch
2-ch
Up to 720p
resolution
Up to 1080p resolution
Audio
compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA
output
1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024
× 768/60Hz
Encoding
resolution
720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
2CIF@6fps;
Sub-stream:
4CIF/2CIF@6fps;

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
