HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
165
Chapter 9 POS Configuration
This chapter is applicable to DS-7300/8100HQHI-F/N and DS-7300/8100/9000HUHI-F/N series DVR
only.
9.1 Configuring POS Settings
Step 1 Enter the POS settings interface.
Menu > Configuration > POS > POS Settings
Step 2 Select the POS from the drop-down list. Up to 8 POS units are selectable.
Step 3 Check the checkbox to enable the POS function.
Figure 9-1 POS Settings
Step 4 Filter the POS privacy information if needed.
1) Click after Privacy Settings to enter POS Privacy Information Filtering interface.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
