HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
37
9
JOG SHUTTLE
Control
Moves the active selection up and down in a menu.
Cycles through different channels in live view mode.
Jumps 30s forward/backward in video files in the
playback mode.
Controls the movement of the PTZ camera in PTZ
control mode.
10
POWER ON/OFF
Power on/off switch.
1.2 IR Remote Control Operations
The DVR may also be controlled with the included IR remote control, shown in Figure 1-8.
Batteries (2×AAA) must be installed before operation.
Figure 1-9 Remote Control

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
