Digital Video Recorder User Manual
228
Figure 14-10 Initialize Added NetHDD
14.3 Managing HDD Group
14.3.1 Setting HDD Groups
Purpose
Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a
particular HDD group through HDD settings.
Step 1 Enter the Storage Mode interface.
Menu > HDD > Advanced
Step 2 Set the Mode to Group, as shown in Figure 14-11.
Figure 14-11 Storage Mode Interface
Step 3 Click the Apply button and the following Attention box will pop up.
Figure 14-12 Attention for Reboot
Step 4 Click the Yes button to reboot the device to activate the changes.
Step 5 After reboot of device, enter the HDD Information interface.
Menu > HDD > General
Step 6 Select HDD from the list and click the icon to enter the Local HDD Settings interface,
as shown in Figure 14-13.
