HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
269
(HDTVI or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
18.1.3 DS-7200HGHI-E2
Model
DS-7208HGHI-E2
DS-7216HGHI- E2
Video/
Audio input
Video compression
H.264+/H.264
Analog and HDTVI
video input
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Supported camera
types
720p25, 720p30, CVBS
IP video input
2-ch
Up to 1080p resolution
Audio compression
G.711u
Audio
input/Two-way
audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA output
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Encoding resolution
720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps
(N)
Sub-stream:
4CIF/2CIF@6fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 4 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
8-ch
16-ch

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
