18.1.12 DS-7200HUHI-F1/N
Model
DS-7204HUHI-F1/N
DS-7208HUHI-F1/N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch
8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
HDTVI input
1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60, 3 MP
AHD input
1080p25, 1080p30, 720p25, 720p30
HDCVI input
1080p25, 1080p30, 720p25, 720p30
CVBS input
Support
IP video input
2-ch
Up to 4 MP resolution
Audio
compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC:
704 × 480
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60
Hz
VGA: 1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Encoding
resolution
3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
3 MP@15fps;
1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
