HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
250
Figure 16-6 Import/Export Configuration File
Step 2 Click the Export button to export configuration files to the selected local backup device.
Step 3 To import a configuration file, select the file from the selected backup device and click the
Import button. After the import process is completed, you must reboot the DVR.
After having finished the import of configuration files, the device will reboot automatically.
16.5 Upgrading System
Purpose
The firmware on your DVR can be upgraded by local backup device or remote FTP server.
16.5.1 Upgrading by Local Backup Device
Step 1 Connect your DVR with a local backup device where the update firmware file is located.
Step 2 Enter the Upgrade interface.
Menu > Maintenance > Upgrade
Step 3 Click the Local Upgrade tab to enter the Local Upgrade interface, as shown in Figure 16-7.
Figure 16-7 Local Upgrade Interface
Step 4 Select the update file from the backup device.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
