Digital Video Recorder User Manual

Figure 3-1 Right-click Menu

3.2.2 Switching Main/Aux Output



Except –HGHI and DS-7100HQHI-F/N series DVR, other series DVR support Aux/Main

output switch. Refer to the tables of Chapter 3.2 Operations in Live View Mode for the main

and aux output relationship.



For the DVR with CVBS output, the CVBS output only serves as the aux output or live view

output.

Step 1 Use the mouse wheel to double-click on the HDMI1/VGA, or HDMI2, or HDMI/VGA, or

HDMI, or VGA output screen, and the following message box pops up.

Figure 3-2 Switch Main and Aux Output

Step 2 Use the mouse wheel to double-click on the screen again to switch to the aux output, or

click Cancel to cancel the operation.

Step 3 Select the Menu Output Mode to others from the right-click menu on the monitor.

Step 4 On the pop-up message box, click Yes to reboot the device to enable the selected menu

output as the main output.

You can select the Menu Output Mode under Menu>Configuration>General>More Settings to

Auto, HDMI1/VGA and HDMI2 (for DS-7300/8100/9000HUHI-F/N) or Auto, HDMI and VGA (for
