HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
129
If there are record files for that camera in that day, in the calendar, the icon for that day is
displayed as . Otherwise it is displayed as .
Playback Interface
You can select the main stream or sub stream from the dropdown list for playback.
You can also use the toolbar in the bottom part of Playback interface to control playing progress,
as shown in the following figure.
Figure 6-4 Playback Interface
Select the channel(s) if you want to switch playback to another channel or execute simultaneous
playback of multiple channels.
Figure 6-5 Toolbar of Playback
Table 6-1 Detailed Explanation of Playback Toolbar
Button
Operation
Button
Operation
Button
Operation
/
Audio
on/Mute
/
Start/Stop
clipping
Lock File
Add default
tag
Add
customized tag
File
management
for video clips,
locked files and

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
