HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
187
Step 1 Enter the VCA settings interface.
Menu> Camera> VCA
Step 2 Select the camera to configure the VCA.
You can click the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.
Step 3 Select the VCA detection type to PIR Alarm.
Step 4 Click to configure the trigger channel, arming schedule and linkage action for the PIR
alarm.
Step 5 Click the Rule Settings button to set the rules. Please refer to the Chapter 10.1 Face
Detection for instructions.
Step 6 Click Apply to activate the settings.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
