Digital Video Recorder User Manual
294
Model
DS-7204HUHI-F2
/N
DS-7208HUHI-F2
/N
DS-7216HUHI-F2
/N
Sub-stream:
WD1/4CIF@12fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 10 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Cloud P2P, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA
2 SATA interfaces
Capacity
Up to 6 TB capacity
External
interface
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
Network
interface
1, RJ45 10M/100M
self-adaptive
Ethernet interface
1, RJ45 10M/100M/1000M self-adaptive
Ethernet interface
USB interface
2 × USB 2.0
Front panel: 1× USB 2.0
Rear panel: 1×USB 3.0
Serial interface
RS-485 (half-duplex)
Alarm in/out
4/1
8/4
16/4
General
Power supply
12 VDC
Consumption
(without HDD)
≤ 15 W
≤ 20 W
≤ 25 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
