HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
298
Model
DS-7604HUHI-F1/
N
DS-7608HUHI-F2
/N
DS-7616HUHI-F2
/N
General
Power supply
12 VDC
Consumption
(without
HDD)
≤ 15 W
≤ 20 W
≤ 40 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
315 × 242 × 45 mm
(12.4 × 9.5 × 1.8
inch)
380 × 320 × 48 mm
(14.9× 12.6 × 1.9 inch )
Weight
(without
HDD)
≤ 2 kg (4.4 lb)

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
