l Cross screwdriver
l ESD wrist strap
Installing an SCM/SWM
SG-6000-X10800 supports up to two SCMs and two SWMs. SCM is located in the slot SCM0
and SCM1 of the back panel, and SWM is located in the slot SWM0 and SWM1 of the back panel.
The following takes SCM as an example to introduce how to install an SCM or SWM. To install an
SCM, take the following steps:
1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to
an ESD point on the chassis. See ESD Prevention.
2. Take SCM out from its antistatic bag.
3. Identify the slot of SCM.
4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and
remove the plate, see Replacing an Expansion Module of SG-6000-X10800.
5. Position the SCM so that its front side faces you. Make sure that the lever is on the down-
side and the SCM module is plain with the outside edge of the expansion slot. Rotate the
Chapter 3 Installation 94
