Connecting the DC Power Cable of SG-6000-X7180
To power the appliance with DC power source, use DC power cables to connect the appliance
and the external DC power source. Hillstone does not provide DC power cables.
Notes: Before performing the procedure, ensure that the cable is not connected
with any power source and make sure the cables will not be powered on during the
process.
To connect the DC power cable to the appliance, take the following steps:
1. Make sure the power cable is not connected to any power source and there is no chance it
will be powered during the process.
2. Ensure that the power source voltage is in accordance with required voltage specified in Sys-
tem Parameters.
3. Ensure that the DC power module has been properly installed according to the Installing a
DC Power Module.
4. Use a DC cable to connect the "+" , "RTN" or "V+" terminal of the appliance to the "+" ter-
minal of the power source; use another DC cable to connect the "-" ,"-48V" or "V-" terminal
to the “-” terminal of the power source.
5. Verify the connection is correct and fasten the cables using a screwdriver.
6. To connect more DC power cables, repeat Step 1 to 5.
Powering on/off the Device
Powering on/off SG-6000-X10800/X9180
To power on the device, if the power modules are connected with the device at the same time
(for example, the machine room is powered on again after outage), the device will be automatically
121
Chapter 3 Installation
