LED Color/Status Description
SYS
(on the
expansion
module)
Green/Always on The module is booting.
Green/Blinking The module is working normally.
Red/Always on The module has failed to start or has a con-
nection error.
Off The module is powered off or has been ejec-
ted.
LED on
the power
supply
Green/Always on The power module is working normally.
Green/Blinking The power module is standby.
Red/Always on The fan of power module or voltage output has
failed.
Red/Blinking The power module is using overcurrent pro-
tection.
Off No power input.
LED on
the fan
tray
Green/Always on The cooling system is working normally.
Red/Always on One or more fans have failed.
Off The fan tray is not fully inserted, or it has a cir-
cuit error.
System Parameters
The following table describes the system parameters of SG-6000-X10800, SG-6000-X9180 and
SG-6000-X7180.
Item Description
Fixed Ports SG-6000-X7180 4 Combo ports (e0/0 is MGT port;
others are HA ports)
18
Chapter 1 Product Profile
