No.
Label &
Description
No.
Label &
Description
No. Label & Description
(HA ports)
7 CON: Con-
sole port
14 Slot1 - Slot6:
Slot status
LED
- -
Back Panel
SG-6000-X10800 back panel consists of eight power supply slots, two SCM slots, two SWM
slots, one air outlet, one ESD point, one power switch, one CLR button and two grounding
screws.
SG-6000-X10800 Back Panel is shown as below:
SG-6000-X9180 back panel consists of four power supply slots, two SCM slots, two SWM slots,
one fan tray, one ESD point, one power switch, one CLR button and two grounding screws.
SG-6000-X9180 Back Panel is shown as below:
8
Chapter 1 Product Profile
